SOUTHSIDE STAGE @ XL LIVE: TECH SPECS

STAGE / RIGGING / AMENITIES

50’w x 30’ Stage deck
Roof Structure 25’h off deck with 6x rigging points on steel I-beam to hang 3x 48’L 20”w x 30’h double
hung truss. Each point rated to 2000lbs with a 1-ton chain motor fitted to each.
2x Speaker hangs 25’h off deck rated at 1000lbs each outfitted with a 1⁄2 ton chain motor


POWER
400amp 208v 3 Phase Power with 200a 3ph distro, 2x single phase 100amp distros, 50amp shore power
available for busses/rv’s


AUDIO
24x RCF HDL10a powered line array modules (10 hung per per side/4 as front fill)
8x RCF Sub9006 dual 18” powered subwoofers
8x Turbososund TSP112an 12” powered 2-way stage monitors/1x Turbosound TSP118an powered 18”
subwoofer for drum box
2x Behringer Wing Digital Mixing Consoles (1 foh/1 monitors)
2x Midas DL32 Digital Stage Boxes
32 Channel Copper Split Snake
(4) Shure SM58 wireless vocal mics• (8) Shure SM58• (6) Shure Sm57• (2) Shure Beta52A• (3) Shure SM81•
(3) Sennheiser e604• (6) Klark Teknik DN100 DI Box


LIGHTING
8x Clay Paky Sharpy Beam

8x Clay Paky Sharpy Wash

6x Elation Cuepix Blinder WW2 LED Lights

6x Elation Cuepix Panel 5x5 RGB LED Lights
6x Martin Viper AirFX
6x Clay Paky Mythos2

6x Martin Mac Viper Performance Moving Lights w/ Framing Shutter

2x Altman Lumminator Follow Spot
2x Chauvet Amhaze Stadium Hazer
MA2 on PC Control Rig


VIDEO
20’w x 10’ P4 IP rated LED wall with NOVAstar processing and Resolume Arena 6 Media Server
Blackmagic Designs Atem Mini Pro ISO 4 channel video switcher/encoder
1x Sony NX5U Camcorder with TerraDeck Wireless pack

3x Sony 1080p PTZ cams
1x Sony Ptz Cam Controller
